Wax Exposed Assembly

LF Group Shower Control - Model-554-270-LF

ECO-MIX ™ Group / Individual Shower Control Unit, Bronze body, Locked temperature adjustment cap (vandal resistant), Copper encapsulated thermostat assembly with polymer thermoplastic shuttle, Stainless steel springs, Buna-N O'rings, Integral check valves on hot and cold inlets, Tempered outlet ball valve,Color coded dial thermometer (0 to140ºF, -10º to 60ºC), Bottom inlets, back outlet, Factory assembled and tested Valve is certified to meet Low-Lead requirements of wetted surface area containing less than 0.25% lead by weight. All other fittings and components, the sum total of which comprise the wetted surface of this product, contains, less than one quarter of one percent of lead by weight.

Downloads
Specification
Inlets 1/2"
Maximum Flow(GPM) 12
Minimum Flow(GPM) 0.25
Outlet 1/2"
Description
Chrome Plated Finish CP
Megatron Nucleus Installed
