XL Exposed Assembly
Lead Free Recirculation Piping Assembly - XL-82-LF-DT-RF-R34
ECO-MIX ™ Thermostatic Water Mixing Valve with integral combination checkstops with strainers. 125 PSI (8.6 BAR) maximum operating pressure, Copper encapsulated thermostatic assembly with Stainless Steel shuttle, locking temperature regulating handle. Internal parts stainless steel, integral wall support for easy mounting, Outlet ball valve, Thermometer and pressure gauge on outlet assembly, 3/4" Return loop with thermometer, Ball valve, Leonard 3/4" ARV automatic return valve, (return limiter), Check valves on either side of ARV. Complete unit mounted on heavy duty strut, for ease of installation. Valve assembly rough bronze finish, Factory assembled and tested Valve is certified to meet Low-Lead requirements of wetted surface area containing less than 0.25% lead by weight. All other fittings and components, the sum total of which comprise the wetted surface of this product, contain less than one quarter of one percent of lead by weight.
CHECK REPAIR KIT - KIT 2/50
|Return Piping 1", ARV replaced with 1" Circuit Setter||RPI|
|Sight Flow Indicator, ball style||SFI|
