Cabinet Assembly Lead Free Thermostatic Point of Use Mixing Valve

LF Thermostatic Mixing Valve - 369-LF-STSTL-REC

Lead free bronze body, Locked temperature adjustment cap (vandal resistant), Copper encapsulated thermostat assembly with polymer thermoplastic shuttle, Stainless steel springs, Buna-N O-rings, Integral check valves on hot and cold inlets, recessed cabinet with cylinder lock This product is certified to meet Low Lead requirements of wetted surface area containing less than 0.25% lead by weight. All other fittings and components, the sum total of which comprise the wetted surface of this product, contain less than one quarter of one percent of lead by weight.

Downloads
Specification
Inlets 3/4"
Minimum Flow(GPM) 1
Outlet 3/4"
Overall Height 10
Overall Width 5
Description
Baked White Exposed Cabinet BWE-EXP
Baked White Recessed Cabinet BWE-REC
Chrome Plated Finish CP
Dial Thermometer on Outlet DT
Lead free ball valve BV-LF
Right Hand Hinge RHH
Stainless Steel Exposed Cabinet STSTL-EXP
Stainless Steel Recessed Cabinet STSTL-REC
Sweat Connections SW
Megatron Nucleus Installed
