Wall Mounted Shower System w/ H-10 adjustable ball joint shower head, 2.5 GPM

Surfashower® - SS-7600-102

Copper encapsulated thermostat assembly with brass shuttle, compensates for temperature fluctuations induced by water temperature and pressure changes Built-in shutoff for single handle operation Integral checkstops Cast wall flange and lever handle, polished chrome plated Maximum operating pressure: 125 PSI (860 KPA) Adjustable high temperature limit stop set for 110°F* (43°C) Color-coded dial ½” flexible stainless steel hose on inlets Capacity of 4 GPM (15 L/min) H-10 adjustable spray ball joint shower head, 2.5 GPM (95 l/min.) max. Exposed parts chrome plated, vandal resistant Maximum supply pressure: 125 PSI (860 KPA) 18 Ga. Stainless steel cover Soap dish Factory assembled and tested
Downloads
Specification
Inlets 1/2"
Options
3ISA models only, adjustable shower head ADJ
Back inlet connections BC
Brass shower head, ball joint, chrome plated C102S
Integral stainless steel extension to ceiling, specify length VX
Metering valve, push type, fixed cycle LV-477
Megatron Nucleus Installed
