Wall Mounted Shower System, ADA Compliant

Surfashower® - SS-7600-104-D2L/501P(G)-44

Copper encapsulated thermostat assembly with brass shuttle, compensates for temperature fluctuations induced by water temperature and pressure changes Built-in shutoff for single handle operation Integral checkstops Cast wall flange and lever handle, polished chrome plated Maximum operating pressure: 125 PSI (860 KPA) Adjustable high temperature limit stop set for 110°F* (43°C) Color-coded dial ½” flexible stainless steel hose on inlets Capacity of 4 GPM (15 L/min) H-03 adjustable spray ball joint shower head, 2.5 GPM (95 l/min.) Cast flanged shower head fitting. Exposed parts chrome plated, vandal resistant Maximum supply pressure: 125 PSI (860 KPA) 18 Ga. Stainless steel cover Soap dish D-2L inline diverter valve with lever handle 501P(G) hand shower, 2.5 GPM (9.5 l/min) 69” (1753mm) hose, 24” (610mm) glide bar, double check valve assembly, supply elbow Sloping top cap with regular bottom cap Factory assembled and tested
Downloads
Specification
Inlets 1/2"
Description
Integral stainless steel extension to ceiling, specify length VX
