Wall Mounted Shower System, ADA Compliant

Surfashower® - SS-7600-501P(G)-30

Copper encapsulated thermostat assembly with brass shuttle, compensates for temperature fluctuations induced by water temperature and pressure changes Built-in shutoff for single handle operation Integral checkstops Cast wall flange and lever handle, polished chrome plated Maximum operating pressure: 125 PSI (860 KPA) Adjustable high temperature limit stop set for 110°F* (43°C) Color-coded dial ½” flexible stainless steel hose on inlets Capacity of 4 GPM (15 L/min) Exposed parts chrome plated, vandal resistant Maximum supply pressure: 125 PSI (860 KPA) Soap dish 501P(G)-30 hand shower, 2.5 GPM (9.5 l/min.) max. flow rate, 69” (1753mm) hose, 30” (760mm) glide bar, double check valve assembly, supply elbow. Factory pre-assembled with 18 gauge stainless steel cover, #4 finish, with top and bottom caps.
Downloads
Specification
Inlets 1/2"
Description
Integral stainless steel extension to ceiling, specify length VX
Left side bar LHB
Quick disconnect fitting QD
Right hand bar RHB
Megatron Nucleus Installed
