Bi-Metal Master Mixing Valve with Cabinet Assembly

Lead Free Recirculation Piping Assembly - TM-186-1520B-LF-DT-RF-R34

ECO-MIX ™ Cabinet Assembly Large Type TM Thermostatic water mixing valve, adjustable high temperature limit stop, inlet checkstops, wall support, outlet ball valve. Small Type TM Thermostatic water mixing valve, adjustable high temperature limit stop, integral checkstops, outlet ball valve, Inlet manifold piping. Dura-trol® solid bimetal thermostat directly linked to valve porting to control the intake of hot and cold water and compensate for supply temperature or pressure fluctuations. Dura-trol® is highly responsive and cannot be damaged by extremes in temperature. Adjustable high temperature limit stop* set for 120ºF (49ºC) Combination checkstops, unions, strainers on inlets wall support, plastic handle. Dial thermometer and pressure gauge on outlet, 3/4” Return loop with dial thermometer, Ball valve, ¾” Leonard ARV automatic return valve, (return limiter). Check valves on either side of Circuit Setter, Complete unit mounted in a cabinet with, double door with a T handle lock , for ease of installation. Valve assembly rough bronze finish. Factory assembled and tested Valve assembly is certified to meet Low-Lead requirements of wetted surface area containing less than 0.25% lead by weight. All other fittings and components, the sum total of which comprise the wetted surface of this product, contain less than one quarter of one percent of lead by weight.
Repair Kits
LARGE VALVE REPAIR KIT - KIT R/125
LARGE VALVE CHECK REPAIR KIT - KIT 2/50Y

SMALL VALVE REPAIR KIT - KIT R/28
SMALL VALVE CHECK REPAIR KIT - KIT 4/M20
Downloads
Specification
Inlets 1 1/4"
Maximum Flow(GPM) 165
Minimum Flow(GPM) 1
Outlet 1 1/2"
Overall Depth 10"
Overall Height 40"
Overall Width 36"
Options
1" Recirculation Piping R1
Baked White Exposed Cabinet BWE-EXP
Baked White Recessed Cabinet BWE-REC
Sight Flow Indicator, ball style SFI
Stainless Steel Exposed Cabinet STSTL-EXP
Stainless Steel Recessed Cabinet STSTL-REC
Megatron Nucleus Installed
