Lead Free Recirculation Piping Assembly - TM-186-920B-LF-DT-RF-R34
ECO-MIX ™ Cabinet Assembly Large Type TM Thermostatic water mixing valve, adjustable high temperature limit stop, inlet checkstops, wall support, outlet ball valve. Small Type TM Thermostatic water mixing valve, adjustable high temperature limit stop, integral checkstops, outlet ball valve, Inlet manifold piping. Dura-trol® solid bimetal thermostat directly linked to valve porting to control the intake of hot and cold water and compensate for supply temperature or pressure fluctuations. Dura-trol® is highly responsive and cannot be damaged by extremes in temperature. Adjustable high temperature limit stop* set for 120ºF (49ºC) Combination checkstops, unions, strainers on inlets wall support, plastic handle. Dial thermometer and pressure gauge on outlet, 3/4” Return loop with dial thermometer, Ball valve, ¾” Leonard ARV automatic return valve, (return limiter). Check valves on either side of Circuit Setter, Complete unit mounted in a cabinet with, double door with a T handle lock , for ease of installation. Valve assembly rough bronze finish. Factory assembled and tested Valve assembly is certified to meet Low-Lead requirements of wetted surface area containing less than 0.25% lead by weight. All other fittings and components, the sum total of which comprise the wetted surface of this product, contain less than one quarter of one percent of lead by weight.
|Return Piping Size||3/4"|
